## MCQs on RLC Circuit

**1. A 6.8 kΩ resistor, a 7 mH coil, and a 0.02 μF capacitor are in parallel across a 17 kHz ac source. The coil’s internal resistance Rw is 30 Ω. The equivalent parallel resistance, Rp (eq) is**

(a) 1,878 Ω

(b) 18,780 Ω

(c) 18,750 Ω

(d) 626 Ω

**Answer**

Answer: (b) 18,780 Ω

**2. A 15 kΩ resistor, a 220 μH coil, and a 60 pF capacitor are in series across an ac source. What is the bandwidth of the circuit?**

(a) 138 MHz

(b) 10,866 Hz

(c) 1,907 Hz

(d) 138 kHz

**Answer**

Answer: (b) 10,866 Hz

**3. A 90 Ω resistor, a coil with 30 Ω of reactance, and a capacitor with 50 Ω of reactance are in series across a 12 V ac source. The current through the resistor is**

(a) 9 mA

(b) 90 mA

(c) 13 mA

(d) 130 mA

**Answer**

Answer: (d) 130 mA

**4. The total impedance, expressed in polar form for a certain series RLC circuit with a 200 Hz, 15 V ac source has the following values: R = 12 Ω, C = 80 μF, and L= 10 mH is**

(a) 12.28 ㄥ12.34^{0} Ω

(b) 12.57 ㄥ12.34^{0} Ω

(c) 9.95 ㄥ12.34^{0} Ω

(d) 12.62 ㄥ12.34^{0} Ω

**Answer**

Answer: (a) 12.28 ㄥ12.34^{0} Ω

**5. If the resistance in parallel with a parallel resonant circuit is reduced, the bandwidth**

(a) Disappears

(b) Becomes Sharper

(c) Increases

(d) Decreases

**Answer**

Answer: (d) Decreases

**6. To tune a parallel resonant circuit to a higher frequency, the capacitance should be**

(a) Increased

(b) Decreased

(c) Left alone

(d) Replaced with inductance

**Answer**

Answer: (b) Decreased

**7. A 15 Ω resistor, an inductor with 8 Ω inductive reactance, and a capacitor with 12 Ω capacitive reactance are in parallel across an ac voltage source.**

(a) 12.7 Ω

(b) 127 Ω

(c) 4.436 Ω

(d) 6,174 Ω

**Answer**

Answer: (a) 12.7 Ω

**8. What is the value of resonant frequency if the value of C in a series RLC circuit is decreased?**

(a) Is not affected

(b) Increases

(c) Is reduced to zero

(d) Decreases

**Answer**

Answer: (b) Increases

**9. In a series RLC circuit that is operating above the resonant frequency the current**

(a) Lags the applied voltage

(b) Leads the applied voltage

(c) Is in phase with the applied voltage

(d) Is zero

**Answer**

Answer: (a) Lags the applied voltage

**10. An inductor with a reactance of 120 Ω, a capacitor with a reactance of 120 Ω and a 24 Ω resistor are in series across a 60 V source. The circuit is at resonance. The voltage across the inductor is**

(a) 60 V

(b) 660 V

(c) 30 V

(d) 300 V

**Answer**

Answer: (d) 300 V
