NCERT Solutions for Class 12th Physics Ch 5 Magnetism and Matter – Solved Exercises
Chapter 5 Magnetism And Matter NCERT Class 12 Physics Questions and Solutions are explained by subject experts and it is arranged based on CBSE Syllabus and NCERT guidelines. However, these NCERT Exercise Questions and answers of Class 12 Physics Chapter 5 Magnetism And Matter are most helpful to the students for their Homeworks and Assignments also.
Answer the following questions regarding earth’s magnetism :
(a) A vector needs three quantities for its specification. Name the three independent quantities conventionally used to specify the earth’s magnetic field.
(b) The angle of dip at a location in southern India is about 18°. Would you expect a greater or smaller dip angle in Britain ? (C.B.S.E. 1995)
(c) If you made a map of magnetic field lines at Melbourne in Australia, would the lines seem to go into the ground or come out of the ground ?
(d) In which direction would a compass free to move in the vertical plane point to, if located right on the geomagnetic north or south pole ? (C.B.S.E. 1995)
(e) The earth’s field, it is claimed, roughly approximates the field due to a dipole of
magnetic moment 8 x 1022 JT_1 located at its center. Check the order of magnitude of this number in some way.
(f) Geologists claim that besides the main magnetic NS poles, there are several local poles on the earth’s surface oriented in different directions. How is such a thing possible at all ?
- Angle of dip or magnetic inclination, δ Galvanometer resistance, G = 12 Q The galvanometer can be converted into the voltmeter of range 0 to V (here V = 18 V) by connecting a high series resistance R given by
- Magnetic declination, θ
- Horizontal component of magnetic field of earth BH.
(b) It is about 70° in Britain because it is closer to the magnetic north pole of earth.
(c) The magnetic field lines due to the magnetism of earth would seem to come out of the ground at Melbourne in Australia because this region is in the Southern hemisphere of earth where north pole of earth’s magnet lies.
(d) Compass can point in any direction because it is free to move in horizontal plane but at magnetic poles the magnetic field of earth is exactly vertical so there will be no horizontal component of the magnetic field to effect the compass.
(e) Using the formula for magnetic field on the equatorial line of a magnetic dipole i.e.
This value tells the order of magnitude of magnetic field of earth.
(f) Geologists are correct to think so because it is an approximation to consider the magnetic field of earth to be a single dipole field. The magnetised mineral deposits can be treated as local dipoles on earth.
Answer the following questions :
(a) The earth’s magnetic field varies from point to point in space. Does it also change with time ? If so, on what time scale does it change appreciably ?
(b) The earth’s core is known to contain iron. Yet geologists do not regard this as a source of the earth’s magnetism. Why ?
(c) The charged currents in the outer conducting regions of the earth’s core are thought to be responsible for earth’s magnetism. What might be the ‘battery’ (i.e. the source of energy) to sustain these currents ?
(d) The earth may have even reversed the direction of its field several times during its history of 4 to 5 billion years. How can geologists know about the earth’s field in such distant past ?
(e) The earth’s field departs from its dipole shape substantially at large distances (greater than about 30,000 km). What agencies may be responsible for this distortion ?(f) Interstellar space has an extremely weak magnetic field of the order of 1012 T. Can such a weak field be of any significant consequence ? Explain.
(a) Although appreciable change can take a few hundred years yet change with time is very much there.
(b) Molten iron has a temperature more than Curie temperature so it is not ferromagnetic in nature.
(c) Probably radioactivity (i.e. emission of a, P and y particles from the nuclei) present in the interior of earth is responsible for it.
(f) During solidification of some rocks, the magnetic field of earth gets weakly recorded in these rocks. Geomagnetic history of these rocks can be traced by making analysis of such rocks.
(e) Ionosphere of earth consists of charged ions. Motion of these ions causes a magnetic field which affects the magnetic field of earth at large distances from earth. The magnetic field due to ions depends upon extra terrestrial disturbances like solar wind.
(f) At very-very large distances like interstellar distances the small fields can significantly affect the charged particles like that of cosmic rays. For small distances, the deflections are not noticeable for small fields but at very large distances the deflections are significant.
clearly small value of B gives a very large value of radius R
A short bar magnet placed with its axis at 30° with a uniform external magnetic field of 0.25 T experiences a torque of magnitude equal to 4.5 X 10-2 J. What is the magnitude of magnetic moment of the magnet ?
Using τ- MB sin θ, we get
A short bar magnet of magnetic moment m = 0.32 JT-1 is placed in a uniform magnetic field of 0.15 T. If the bar is free to rotate in the plane of the field, which orientation would correspond to its (a) stable, and (b) unstable equilibrium ? What is the potential energy of the magnet in each case ?
A closely wound solenoid of 800 turns and area of cross section 2.5 x 10-4 m2 carries a current of 3.0 A. Explain the sense in which the solenoid acts like a bar magnet. What is its associated magnetic moment ?
Using M = NIA, we get
M = 800 x 3 x 2.5 x 10-4 = 0.60 JT-1.
The sense is determined by the direction of the current.
If the solenoid in Exercise 5.5 is free to turn about the vertical direction and a uniform horizontal magnetic field of 0.25 T is applied, what is the magnitude of the torque on the solenoid when its axis makes an angle of 30° with the direction of the applied field ?
Using x = MB sin θ, we get
x = 0.6 x 0.25 x sin 30
= 0.6 x 0.25 x 12
= 0.3 x 0.25 = 0.075 Nm
= 7.5 x 10-2 Nm.
A bar magnet of magnetic moment 1.5 JT-1 lies aligned with the direction of a uniform magnetic field of 0.22T.
(a) What is the amount of work required by an external torque to turn the magnet so as to align its magnetic moment, (i) normal to the field direction, (ii) opposite to the field direction ?
(b) What is the torque on the magnet in cases (i) and (ii)?
A closely wound solenoid of 2000 turns and area of cross-section 1.6 X 10-4 m2, carrying a current of 4.0 A, is suspended through its center allowing it to turn in a horizontal plane.
(a) What is the magnetic moment associated with the solenoid ?
(b) What is the force and torque on the solenoid if a uniform horizontal magnetic field of 7.5 x 10-2 T is set up at an angle of 30° with the axis of the solenoid?
(a) Using M = NIA, we get
M = 2000 x 4 x 1.6 x 10-4
= 1.28 Am2
Direction of M is as per sense of current using the right handed rule.
(b) Torque, x = MB sin 0
= 1.28 x 7-5 x 10-2 x sin 30°
= 4.8 x 10-2 N m
Force is zero because of uniform field.
A circular coil of 16 turns and radius 10 cm carrying a current of 0.75 A rests with its plane normal to an external field of magnitude 5.0 x 10-2 T. The coil is free to turn about an axis in its plane perpendicular to the field direction. When the coil is turned slightly and released, it oscillates about its stable equilibrium with a frequency of 2.0 s_1. What is the moment of inertia of the coil about its axis of rotation ?
A magnetic needle free to rotate in a vertical plane parallel to the magnetic meridian has its north tip pointing down at 22° with the horizontal. The horizontal component of the earth’s magnetic field at the place is known to be 0.35 G. Determine the magnitude of the earth’s magnetic field at the place.
At a certain location in Africa, a compass points 12° west of the geographic north. The north tip of the magnetic needle of a dip circle placed in the plane of magnetic meridian points 60° above the horizontal. The horizontal component of the earth’s field is measured to be 0.16 G. Specify the direction and magnitude of the earth’s field at the location.
Using BH = B cos δ, we get
Direction of B is 12° west of geographic meridian making upward angle of 60° with horizontal.
A short bar magnet has a magnetic moment of 0.48 JT-1. Give the direction and magnitude of the magnetic field produced by the magnet at a distance of 10 cm from the center of the magnet on (a) the axis, (b) the equatorial lines (normal bisector) of the magnet.
On axial line
A short bar magnet placed in a horizontal plane has its axis aligned along the magnetic north-south direction. Null points are found on the axis of the magnet at 14 cm from the center of the magnet. The earth’s magnetic field at the place is 0.36 G and the angle of dip is zero. What is the total magnetic field on the normal bisector of the magnet at the same distance as the null-points (i.e., 14 cm) from the center of the magnet ? (At null points, Held due to a magnet is equal and opposite to the horizontal component of earth’s magnetic field.)
Magnetic field at the equatorial line of the magnet is given
If the bar magnet in Exercise 5.13 is turned around by 180°, where will the new null-points be located ?
When magnet is turned around 180°, its south pole lies in the geographical south direction. Hence null point will lie on the equatorial line at a distance x from die center of the magnet.
A short bar magnet of magnetic moment 5.25 x 10-2 JT_1 is placed with its axis perpendicular to the earth’s field direction. At what distance from the center of the magnet, the resultant field is inclined at 45° with the earth’s field on (a) its normal bisector and (b) its axis. Magnitude of the earth’s field at the place is given to be 0.42 G. Ignore the length of the magnet in comparison to the distances involved.
(a) Let resultant magnetic field of a magnet at point P makes an angle θ= 45° with the earth’s field. Therefore,
Answer the following questions :
(a) Why does a paramagnetic sample display greater magnetisation (for the same magnetising field) when cooled ? (C.B.S.E. 1991)
(b) Why is diamagnetism, in contrast, almost independent of temperature ?
(c) If a toroid uses bismuth for its core, will the field in the core be (slightly) greater or (slightly) less than when the core is empty ?
(d) Is the permeability of a ferromagnetic material independent of the magnetic field ? If not, is it more for lower or higher fields ?
(e) Magnetic field lines are always nearly normal to the surface of a ferromagnet at every point. (This fact is analogous to the static electric field lines being normal to the surface of a conductor at every point). Why ?
(f) Would the maximum possible magnetisation of a paramagnetic sample be of the same order of magnitude as the magnetisation of a ferromagnet ?
(a) At lower temperatures, the tendency of dealignment of magnetic dipoles with magnetising field is reduced because of decrease in their random thermal motion.
(b) The induced dipole moment in a diamagnetic sample is opposite to the magnetising field irrespective of the internal thermal motion of the atoms. Thus, diamagnetism is independent of the changes in temperature.
(c) It will be slightly less because bismuth is a diamagnetic substance.
(d) Permeability of a ferromagnetic material depends on applied magnetic field. Permeabliltiy is more for lower magnetic field.
(e) When two media are considered and one of these has μ > > 1, then magnetic field lines meet normally to this medium. Proof of this fact is available from the boundary conditions of magnetic fields (strength of magnetic field B and magnetising intensity H) at the interface of two media.
(f) The maximum possible magnetisation of a paramagnetic sample would be of the same order of magnitude as the magnetisation of a ferromagnetic sample but the paramagnetic sample requires very high magnetising field which may not be practically possible.
Answer the following questions :
(a) Explain qualitatively on the basis of domain picture the irreversibility in the magnetisation curve of a ferromagnet.
(b) The hysteresis loop of a soft iron piece has a much smaller area than that of a carbon steel piece. If the material is to go through repeated cycles of magnetization, which piece will dissipate greater heat energy ?
(c) ‘A system displaying a hysteresis loop such as a ferromagnet is a device for storing memory.’ Explain the meaning of this statement.
(d) What kind of ferromagnetic material is used for coating magnetic tapes in a cassette player, or for budding ‘memory stores’ in a modern computer ?
(e) A certain region of space is to be shielded from magnetic fields. Suggest a method.
(a) It can be observed from the given curve that magnetisation persists even when the external field is removed. This reflects the irreversibility of a ferromagnet.
(b) Heat dissipated per second is directly proportional to the area of the hysteresis loop so carbon steel piece will dissipate greater heat energy.
(c) Magnetisation of a ferromagnet depends upon the applied field as number of cycles of magnetisation given to it. Thus the value of magnetisation can indicate the number of cycles of magnetisation a sample has undergone or in other words the memory with respect to the cycles stands stored in the sample.
(d) Ceramics are used for this purpose. Ferrites which are specially treated barium iron oxides are commonly used.
(e) The space to be shielded is enclosed by soft iron rings. The magnetic field lines remain confined in the ferromagnetic material of the rings and the enclosed space will be free from magnetic effect.
Note. Magnetic shielding is not as effective as electrostatic shielding is.
A long straight horizontal cable carries a current of 2.5 A in the direction 10° south of west to 10° north of east. The magnetic meridian of the place happens to be 10° west of the geographic meridian. The earth’s magnetic field at the location is 0.33 G, and the angle of dip is zero. Locate the line of neutral points (Ignore the thickness of the cable). (At neutral points, magnetic field due to a current-carrying cable is equal and opposite to the horizontal component of earth’s magnetic field.)
Let neutral point lies at a distance x from the cable. Now, at neutral point, magnetic field due to cable is equal in magnitude and opposite in direction of the earth’s magnetic field.
A telephone cable at a place has four long straight horizontal wires carrying a current of 1.0 A in the same direction east to west. The earth’s magnetic field at the place is 0.39 G, and the angle of dip is 35°. The magnetic declination is nearly zero. What are the resultant magnetic fields at points 4.0 cm below the cable ?
A compass needle free to turn in a horizontal plane is placed at the center of circular coil of 30 turns and radius 12 cm. The coil is in a vertical plane making an angle of 45° with the magnetic meridian. When the current in the coil is 0.35 A, the needle points west to east.
(a) Determine the horizontal component of the earth’s magnetic field at the location.
(b) The current in the coil is reversed, and the coil is rotated about its vertical axis by an angle of 90° in the anticlockwise sense looking from above. Predict the direction of the needle. Take the magnetic declination at the place to be zero.
A magnetic dipole is under the influence of two magnetic fields. The angle between the field directions is 60°, and one of the fields has a magnitude of 1.2 x 10-2 T. If the dipole comes to stable equilibrium at an angle of 15° with this field, what is the magnitude of the other field ?
Here B, = 1.2 X 10-2 T,θ1= 15°, θ2 = 45°.
The dipole will be in equilibrium, if torque acting on dipole due to B1 is equal and opposite to the torque acting on dipole due to B2.
That is, MB1 sin = MB2 sin θ2
A monoenergetic (18 keV) electron beam intially in the horizontal direction is subjected to a horizontal magnetic field of 0.40 G normal to the initial direction. Estimate the up
or down deflection of the beam over a distance of 30 cm (me = 9.11 x 10-19 Q.
[Note. Data in this exercise are so chosen that the answer will give you an idea of the effect of earth’s magnetic field on the motion of the electron beam from the electron gun to the screen in a TV set.]
A sample of paramagnetic salt contains 2.0 x 1024 atomic dipoles each of dipole moment 1.5 x 10-23 JT-1. The sample is placed under a homogeneous magnetic field of 0.64 T, and cooled to a temperature of 4.2 K. The degree of magnetic saturation achieved is equal to 15%. What is the total dipole moment of the sample for a magnetic field of 0.98 T and a temperature of 2.8 K ? (Assume Curie’s law).
Magnetic dipole moment of sample,
M = 15% of M (1.5 x 10-23) (2 x 1024)
= 30 JT-1
A Rowland ring of mean radius 15 cm has 3500 turns of wire wound on a ferromagnetic core of relative permeability 800. What is the magnetic field B in the core for a magnetising current of 1.2 A?
The magnetic moment vectors μs and μl; associated with the intrinsic spin angular momentum S and orbital angular momentum Z, respectively, of an electron are predicted by quantum theory (and verified experimentally to a high accuracy) to be given by :
Which of these relations is in accordance with the result expected classically ? Outline the derivation of the classical result.
