MCQ on Biot Savart Law
1. Which is the equation of the magnetic field according to Biot-Savart’s law?
(a) IdIsinθ/r2
(b) (μ0/4π)IdIsinθ/r
(c) (μ0/4π)IdIsinθ/r2
(d) (μ0/4π)IdIsinθ
Answer
Answer: (c) (μ0/4π)IdIsinθ/r2
2. The magnetic field due to a copper rod carrying direct current is
(a) The magnetic field is inside the rod
(b) The magnetic field is outside the rod
(c) Both inside and outside the rod
(d) Neither inside nor outside
Answer
Answer: (c) Both inside and outside the rod
3. Consider a current i flowing through the inner conductor of a coaxial cable and the current returns along the outer conductor of the cable. The value of magnetic induction at a distance r from the axis is
(a) (μ0/4π)(2i/r)
(b) ∞
(c) Zero
(d) (μ0/4π)(2πi/r)
Answer
Answer: (c) Zero
4. To which law of electricity is Biot Savart law of magnetism analogous to
(a) Coulomb’s law
(b) Ohm’s law
(c) Kirchoff’s law
(d) Faraday’s law
Answer
Answer: (a) Coulomb’s law
5. Which of the following properties cannot be calculated from Biot Savart law?
(a) Magnetic field intensity
(b) Flux density
(c) Permeability
(d) Electric field intensity
Answer
Answer: (d) Electric field intensity
6. Consider a circular conductor with 2m radius and 8 A current flowing through it. What is the value of magnetic field intensity at the centre of the circular conductor?
(a) 4π x 10-7 T
(b) 8π x 10-7 T
(c) 8 x 10-7 T
(d) 3π x 107 T
Answer
Answer: (b) 8π x 10-7 T
7. If the strength of the magnetic field at a point r near a long straight current-carrying wire is B. The value of the field at a distance r/2 will be
(a) B/2
(b) B/4
(c) 2B
(d) 4B
Answer
Answer: (c) 2B
8. If the current I flows through the coil of radius r then the field at the centre of the circular coil is
(a) Inversely proportional to I2
(b) Directly proportional to I
(c) Directly proportional to r
(d) Inversely proportional to r2
Answer
Answer: (b) Directly proportional to I
9. Two parallel conductors separated by a distance 2r carries current i in the same direction. The intensity of the magnetic field midway between them is
(a) Zero
(b) μ0 i/r
(c) 4μ0 i/r
(d) μ0 i/4r
Answer
Answer: (a) Zero
10. A straight wire of length 2 metres is taken and a current of 1 Ampere is passed through them. The magnetic field at a point along the axis of the wire at a distance of 3 metres from either end of the wire is given by
(a) μ0 /4π
(b) Zero
(c) μ0 /π
(d) 2μ0 /π
Answer
Answer: (a) Zero
